High Resolution 1920X1080 IPS Display Module 11.9 Inch TFT LCD Modules with 1000 Nits Brightness
Resolution & Pixel Pitch: Various pixel pitches available (e.g., P1.25, P2.5, P4) to ensure high-definition displays for different a
Size & Shape: Customizable screen sizes and shapes, including standard rectangular, curved, and irregul
Brightness & Protection Level: Adjustable brightness (1000 to 5000 nits) and protection levels (e.g., IP65 waterproof) tailored for indoor or outdoor u
Control System & Features: Customizable control systems with options for multiple playback modes, interactive touch functionality, a
Introduction
| Type | TFT IPS Module | Resolution | 1920X1080 |
| Display Type | IPS | Backlight Type | LED Display Screen |
| Brightness | 1000 | Display Size | 11.9 inch |
| Supplier Type | OEM and ODM | Operating Temperature | -10-50 |
| Screen Size | 11.9 | Communication Interface | EDP |
| Resolution | 1920* 1080 | Interface | EDP |
| Luminance | 1000 cd/m2 | Viewing Angle | All |
| Active Area(mm) | 263.23X148.07 | Pixel Pitch(mm) | 0.153*0.153 |
| Pin Number | 30 Pin | Life time(Hrs) | 15000 |
| O.T.(℃) | -10~+50 | Application | Tablet,Notebook,Computer |
