Industrial Grade BOE Original LCD Display Screen LVDS EV101WXM N10 High Contrast Brightness Outdoor Wide Temperature LCD Panel
Resolution & Pixel Pitch: Various pixel pitches available (e.g., P1.25, P2.5, P4) to ensure high-definition displays for different a
Size & Shape: Customizable screen sizes and shapes, including standard rectangular, curved, and irregul
Brightness & Protection Level: Adjustable brightness (1000 to 5000 nits) and protection levels (e.g., IP65 waterproof) tailored for indoor or outdoor u
Control System & Features: Customizable control systems with options for multiple playback modes, interactive touch functionality, a
Introduction
| Type | IPS | Resolution | 1280x800, WXGA 149PPI |
| Display Type | IPS | Backlight Type | LED Display Screen |
| Mounting Type | Panel Mounting | Brightness | 400 cd/m² (Typ.) |
| Display Size | 10.1 inch | Supplier Type | Agent |
| Operating Temperature | -20 ~ 70 °C | Screen Size | 10.1" |
| Communication Interface | LVDS (1 ch, 8-bit) , 40 pins Connector | Active Area | 216.96(W)*135.6(H) mm |
| Outline Size | 228.6(W)*149.2(H) * 3(D) mm | Viewing Angle | 85/85/85/85 (Typ.) |
| Contrast Ratio | 900:1 | Backlight | WLED , 30k hours , with LED driver |
| Display Colors | 16.7M 50% NTSC | Display mode | ADS , Normally black |
| Response time | 30ms | Power Consumption | 4.2W |
