LCD Controller Board LVDS Capacitive Touchscreen Panel Stretched LCD Bar Display 1280x480 12.3 Inch TFT LCD Panel
Resolution & Pixel Pitch: Various pixel pitches available (e.g., P1.25, P2.5, P4) to ensure high-definition displays for different a
Size & Shape: Customizable screen sizes and shapes, including standard rectangular, curved, and irregul
Brightness & Protection Level: Adjustable brightness (1000 to 5000 nits) and protection levels (e.g., IP65 waterproof) tailored for indoor or outdoor u
Control System & Features: Customizable control systems with options for multiple playback modes, interactive touch functionality, a
Introduction
| Type | Capacitive | Application | car, retail, diy screen, industry |
| Interface | DVI VGA, 20 pins LVDS | Features | Capacitive Touch Panel Screen |
| Drive IC | VS-TY2660H-V661 | Product Name | 12.3 Inch Tft Lcd Panel |
| Outline Size | 312.4x130.4x8 (HxVxD)mm | Display Area | 291.84x 109.44 (HxV)mm |
| Board Size | 74mm x 53mm x 12mm | Audio Output | Speaker (4Pin PH1.25 connector) |
| Input Power Adapter | 12Vdc More than 5A. | Input Voltage | 3.3V (Typ.) |
| Touch panel | Capacitive Touch Optional | Interface | 20 pins LVDS (1 ch, 8-bit) , Connector |
