LCD Custom 10.1 Inch 1280*800 Capacitive Touch Panel IPS TFT LCD LVDS Display Option with LED Driver Boards
Resolution & Pixel Pitch: Various pixel pitches available (e.g., P1.25, P2.5, P4) to ensure high-definition displays for different a
Size & Shape: Customizable screen sizes and shapes, including standard rectangular, curved, and irregul
Brightness & Protection Level: Adjustable brightness (1000 to 5000 nits) and protection levels (e.g., IP65 waterproof) tailored for indoor or outdoor u
Control System & Features: Customizable control systems with options for multiple playback modes, interactive touch functionality, a
Introduction
| Type | Standard | Display Size | 10.1 inch |
| Supplier Type | Original manufacturer | Resolution | 1280*800 |
| Active Area | 216.96(H)x135.6(V) mm | Module size | 228.9(W)x148.5(H)x2.85(D) mm |
| LCD Type | IPS TFT Transmissive | Contrast Ratio | 1000:1 |
| Colour Gamut | 50% | Luminance | 300cd/m² |
| Backlight type | 6S6P WLED,25k Hours without LED Driver | Interface | 40pin LVDS |
| Operating Temperature | -20℃~+70℃ |
