OEM 7.0 Inch TFT LCD Display Screen 800x480 Resolution Tax Control Equipment Instrument Display
Resolution & Pixel Pitch: Various pixel pitches available (e.g., P1.25, P2.5, P4) to ensure high-definition displays for different a
Size & Shape: Customizable screen sizes and shapes, including standard rectangular, curved, and irregul
Brightness & Protection Level: Adjustable brightness (1000 to 5000 nits) and protection levels (e.g., IP65 waterproof) tailored for indoor or outdoor u
Control System & Features: Customizable control systems with options for multiple playback modes, interactive touch functionality, a
Introduction
| Type | TFT display screen | Resolution | 800(Horizontal)*480(Vertical) |
| Display Type | TFT | Backlight Type | LED Display Screen |
| Mounting Type | Connector | Brightness | 400 |
| Display Size | 7.0inch | Supplier Type | manufacturer |
| Operating Temperature | -20-70 | Screen Size | 7 inch |
| Communication Interface | 24bit RGB | Driver Ic | EK9713+EK73002 |
| P/N | C070WVI01NE | Product Name | TFT Module Screen |
| Display mode | Normally white | Viewing Angle | 12 O'clock |
| PIN | 50 PIN | Pixel Pitch | 0.1926*0.1790 |
| Viewing Direction | 70 | Contrast | 500 |
| LCM (W x H x D) (mm) | 164.80*99.80*5.5 | Active Area(mm) | 154.08*85.92 |
