OEM ODM Monochrome FSTN Positive 240x160 Graphic COG LCD Display
Resolution & Pixel Pitch: Various pixel pitches available (e.g., P1.25, P2.5, P4) to ensure high-definition displays for different a
Size & Shape: Customizable screen sizes and shapes, including standard rectangular, curved, and irregul
Brightness & Protection Level: Adjustable brightness (1000 to 5000 nits) and protection levels (e.g., IP65 waterproof) tailored for indoor or outdoor u
Control System & Features: Customizable control systems with options for multiple playback modes, interactive touch functionality, a
Introduction
| Type | Graphic | Interface | - |
| Touchscreen | Non-touch | Backlight | LED Display Screen |
| Mounting Type | - | display mode | Positive |
| Display Size | 3.7 Inch | Resolution | 240*160 |
| Viewing Angle | 6H | Operating Temperature | -20~70 ℃ |
| Viewing Area | 77.58*51.6mm(3.05*2.03in) | Name | Graphic LCD Display |
| Resoultion | 240*160 | Module Size | 85.0 x 62.8 x 2.0mm |
| Viewing Area | 77.58 x 51.6mm | Display mode | FSTN, Positive |
| Driving voltage | 3.0v | Controller | ST7586S |
| Operating Temperature | -20~70C | Storage Temperature | -30~80℃ |
| Viewing Angle | 12 O'clock |
