Original Innolux M270HCJ L5B 27 Inch LCD Screen FHD 1920x1080 IPS 75Hz Display Panel for HP Lenovo All in One PC Replacement
Resolution & Pixel Pitch: Various pixel pitches available (e.g., P1.25, P2.5, P4) to ensure high-definition displays for different a
Size & Shape: Customizable screen sizes and shapes, including standard rectangular, curved, and irregul
Brightness & Protection Level: Adjustable brightness (1000 to 5000 nits) and protection levels (e.g., IP65 waterproof) tailored for indoor or outdoor u
Control System & Features: Customizable control systems with options for multiple playback modes, interactive touch functionality, a
Introduction
| Type | TFT | Resolution | 1920(RGB)*1080, FHD 81PPI |
| Display Type | TFT | Backlight Type | WLED |
| Mounting Type | Panel Mounting | Brightness | 250 cd/m² (Typ.) |
| Display Size | 27" | Supplier Type | a-Si TFT-LCD, LCM |
| Operating Temperature | -20-60 | Screen Size | 27" |
| Communication Interface | LVDS (2 ch, 8-bit) , Connector 30 pins | Driver Ic | No Driver |
| Product Name | 27" Display Screen Panel Module | Interface | LVDS (2 ch, 8-bit) , Connector 30 pins |
| Outline Dim. | 607.1*354.1*13.2 (H*V*D) | Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Panle Type | a-Si TFT-LCD, LCM | Model P/N | M270HCJ-L5B |
| Backlight Type | 4 strings WLED , 30K hours , No Driver | Active Area | 597.888(W)*336.312(H) mm |
