Outdoor P6 LED Display Screen Module SMD Full Color High Refresh Waterproof LED Display Panel
Resolution & Pixel Pitch: Various pixel pitches available (e.g., P1.25, P2.5, P4) to ensure high-definition displays for different a
Size & Shape: Customizable screen sizes and shapes, including standard rectangular, curved, and irregul
Brightness & Protection Level: Adjustable brightness (1000 to 5000 nits) and protection levels (e.g., IP65 waterproof) tailored for indoor or outdoor u
Control System & Features: Customizable control systems with options for multiple playback modes, interactive touch functionality, a
Introduction
| specification | Video Wall, Digital Poster, LED display module |
|---|---|
| Usage environment | Outdoor |
| Pixel Pitch | P6 |
| brightness | ≥5500nits |
| ip rating | IP65 |
| Product Dimensions | 192x192mm(7.56x7.56in) |
| resolution | 160x160 pixels |
| Content Management System | Yes |
| Remote Device Management | Yes |
| Control Method | Computer, Remote Controller, Wifi, USB |
| aspect ratio | 16:9, 4:3, 3:2, 1:1, Other |
| Operating Temperature | -20°C To 50°C |
| Contrast Ratio | 6000:1 |
| Color Depth | RGB |
| Display Coating | AG (Anti-Glare) |
| Voltage | AC220-240V |
| Material | Die-Casting Aluminum |
| Operation System | Android, Linux, Tizen OS, WEBOS |
| Storage | 32 G, 64 GB, 128 GB |
| RAM | 4 GB, 8 GB, 16 GB |
| Display Function | Animation, Graphics, Text |
| Screen Type | LED Display Screen |
| application | Outdoor |
| view angle（h/v） | 140°-160° |
| response time | 1/8s |
| media available | Datasheet, Photo, EDA/CAD Models, Other |
| supplier type | Original Manufacturer, OEM, ODM |
| color | full color |
| lifespan (hours) | 100000hours |
| Pixel pitch | P6mm |
| Module size | 192x192mm |
| Module resolution | 32x32 pixels |
| Scan mode | 1/8scan |
| Refresh rate | 3840Hz |
| LED chip | SMD3535 |
| Viewing angle | 140°-160° |
| Certificate | CE ROHS FCC CCC ISO |
| Life span | 100000hours |
