Small Size LCD Panel 1.69 Inch 240*280 IPS TFT LCD Display For Smart Watch
Resolution & Pixel Pitch: Various pixel pitches available (e.g., P1.25, P2.5, P4) to ensure high-definition displays for different a
Size & Shape: Customizable screen sizes and shapes, including standard rectangular, curved, and irregul
Brightness & Protection Level: Adjustable brightness (1000 to 5000 nits) and protection levels (e.g., IP65 waterproof) tailored for indoor or outdoor u
Control System & Features: Customizable control systems with options for multiple playback modes, interactive touch functionality, a
Introduction
| Type | TFT | Resolution | 240x280 |
| Display Type | TFT | Backlight Type | LED Display Screen |
| Brightness | 300cd/m2 | Display Size | 1.69 Inch |
| Supplier Type | factory manufacture wholesale | Operating Temperature | -20℃~70℃ |
| Screen Size | 1.69 Inch | Communication Interface | 4W SPI |
| Driver Ic | JD9851A | Product name | High Quality Small Size Lcd Panel 1.69Inch 240*280 Ips Tft Lcd Display |
| Type | IPS | Interface | MCU |
| Size | 1.69 Inch | Viewing Angle | 80/80/80/80 |
| Luminance | 300cd/m2 | Outline Dimension | 34.70 x 40.70x 3.51mm |
| Active Area | 27.97 x 32.63mm | Touch Panel | Capacitive Touch Optional |
