ST6451D02-2 65 Inch TV Screen Replacement ST6451D02-H UHD 4k Replacement LED LCD Display Panel TV Flat Screen Open Cell
Resolution & Pixel Pitch: Various pixel pitches available (e.g., P1.25, P2.5, P4) to ensure high-definition displays for different a
Size & Shape: Customizable screen sizes and shapes, including standard rectangular, curved, and irregul
Brightness & Protection Level: Adjustable brightness (1000 to 5000 nits) and protection levels (e.g., IP65 waterproof) tailored for indoor or outdoor u
Control System & Features: Customizable control systems with options for multiple playback modes, interactive touch functionality, a
Introduction
| Type | TFT | Resolution | 3840(RGB)x2160, UHD, 68PPI |
| Display Type | HVA | Backlight Type | Without |
| Brightness | 0 | Display Size | 65 inch |
| Supplier Type | China factory directly supply | Operating Temperature | 0 ~ 50 °C(0~90℉) |
| Screen Size | 65 Inch | Communication Interface | V-by-One 8 lane , terminal , 51 pins |
| Driver Ic | bound COF 12 source chips | Contrast Ratio | 5000:1 |
| Color Depth | 1.07B , 100% sRGB | Signal Type | V-by-One 8 lane , 51 pins , Terminal |
| Response time | 6.5 (Typ.)(G to G) ms | Panel Type | a-Si TFT-LCD, LCD Glass , FOB |
| Active Area | 1428.48(W)x803.52(H) mm | Outline(mm) | 1440.78(W)x816.17(H)x1.35(D) mm |
| Driver IC | Bound COF 12 source chips |
