TCC RoHS Compliant 2.6" 128x32 Monochrome Graphic STN LCD Module with 20 Pin Serial Parallel Interface
Resolution & Pixel Pitch: Various pixel pitches available (e.g., P1.25, P2.5, P4) to ensure high-definition displays for different a
Size & Shape: Customizable screen sizes and shapes, including standard rectangular, curved, and irregul
Brightness & Protection Level: Adjustable brightness (1000 to 5000 nits) and protection levels (e.g., IP65 waterproof) tailored for indoor or outdoor u
Control System & Features: Customizable control systems with options for multiple playback modes, interactive touch functionality, a
Introduction
| Type | STN | Display Size | 2.6" |
| Supplier Type | Manufacturer/Factory | Resolution | 128*32 |
| Viewing Angle | 6 O' Clock | Outline Dimensions | 80.6*42.8*13.0mm |
| View Area | 60.0*18.0mm | Active Area | 51.2*14.4mm |
| Controller IC | ST7920/AIP31020 | Interface Type | Serial/parallel port |
| Display mode | STN/Blue/Yellow-green | Backlight Type | LED White/Yellow-green |
| Number of pins | 20 pin |
