Transflective Sunlight Readable 3.5 Inch LCD Display 240*320 QVGA ILI9341V Driver IC LCD Panel
Resolution & Pixel Pitch: Various pixel pitches available (e.g., P1.25, P2.5, P4) to ensure high-definition displays for different a
Size & Shape: Customizable screen sizes and shapes, including standard rectangular, curved, and irregul
Brightness & Protection Level: Adjustable brightness (1000 to 5000 nits) and protection levels (e.g., IP65 waterproof) tailored for indoor or outdoor u
Control System & Features: Customizable control systems with options for multiple playback modes, interactive touch functionality, a
Introduction
| Type | TFT display screen | Resolution | 240(Horizontal)*320(Vertical) |
| Display Type | TFT | Backlight Type | LED Display Screen |
| Mounting Type | Connector | Brightness | 150 |
| Display Size | 3.5" | Supplier Type | manufacturer |
| Operating Temperature | -20-70 | Screen Size | 3.5 inch |
| Communication Interface | 18bits RGB+SPI | Driver Ic | ILI9341V |
| P/N | C035QT01F | Product Name | TFT Module Screen |
| Viewing Angle | 6 O'clock | Display mode | Normal White |
| Pixel Pitch | 0.2235*0.2235 | Viewing Direction | 60 |
| Contrast | 150 | LCM(W*H*D)(mm) | 64.00*85.00*2.93 |
| Active Area(mm) | 53.64*71.52 | Storage Temperature | -30-80 |
