TV Board 10.1" 1366x768 LCD Panel with Touch Screen
Resolution & Pixel Pitch: Various pixel pitches available (e.g., P1.25, P2.5, P4) to ensure high-definition displays for different a
Size & Shape: Customizable screen sizes and shapes, including standard rectangular, curved, and irregul
Brightness & Protection Level: Adjustable brightness (1000 to 5000 nits) and protection levels (e.g., IP65 waterproof) tailored for indoor or outdoor u
Control System & Features: Customizable control systems with options for multiple playback modes, interactive touch functionality, a
Introduction
| Type | Resistive | Communication Interface | USB |
| Application | industry | Interface | LVDS, HD-MI VGA AV USB RF |
| Screen Size | 10.1inch | Type | TFT |
| Dots Format | 1366x768 | Outline Size | 230.62 x 135.81x0.8(HxVxD)mm |
| Display Area | 222.52x 125.11 (HxV) mm | Item No | B101XAN01.3 |
| Connector | 40 Pins LVDS | Touch | 4-wire resistive touch panel |
| Video Input: | HD-MI VGA AV USB RF | Product Name | TV board lcd panel |
| Viewing Angle | 85/85/85/85 (Typ.)(CR 10) (L/R/U/D) |
