YVO027 J01 128x64 OLED Display Module SSD1327 I2C Interface 3-5V Low Power 20~+70C for Instruments Industrial Control
Resolution & Pixel Pitch: Various pixel pitches available (e.g., P1.25, P2.5, P4) to ensure high-definition displays for different a
Size & Shape: Customizable screen sizes and shapes, including standard rectangular, curved, and irregul
Brightness & Protection Level: Adjustable brightness (1000 to 5000 nits) and protection levels (e.g., IP65 waterproof) tailored for indoor or outdoor u
Control System & Features: Customizable control systems with options for multiple playback modes, interactive touch functionality, a
Introduction
| Type | OLED Display Screen | Size | 2.7inch |
| Resolution | 128*64 | Interface | 8-bit Parallel/SPI/IIC |
| Pin Number | 4/7/9 pin | Outline Dimension | 82.3x52.2x2.8 |
| Active Area | 61.41x30.69 | LCD Type | Oled |
| Driver IC | SSD1327 | Operating temperature | -20~+70 |
