YZY Factory Direct 1602H STN Character LCD Display Module with LED Backlight Monochrome in Stock
Resolution & Pixel Pitch: Various pixel pitches available (e.g., P1.25, P2.5, P4) to ensure high-definition displays for different a
Size & Shape: Customizable screen sizes and shapes, including standard rectangular, curved, and irregul
Brightness & Protection Level: Adjustable brightness (1000 to 5000 nits) and protection levels (e.g., IP65 waterproof) tailored for indoor or outdoor u
Control System & Features: Customizable control systems with options for multiple playback modes, interactive touch functionality, a
Introduction
| Type | STN | Resolution | 16*2 character |
| Display Type | STN | Backlight Type | LED Display Screen |
| Display Size | 85*30*11.3 | Supplier Type | Manufacturer |
| Operating Temperature | -20-70C | Communication Interface | 4,8-Bit parallel |
| Driver Ic | ST7066/ST7065 OR Equ. | Part No. | XNY1602H |
| LCD Type | STN | Backlight Type | Yellow Green |
| Display type | STN/Y-G/POSITIVE/TRANSMISSIVE | Viewing Angle | 6 O'clock |
| Driver IC | ST7066/ST7065 OR Equ. | Driver voltage | 5V/(3.3V Optional) |
| Outline Dimension | 85*30*11.3 | Application | industrial control/Medical / Instrumentation/ |
| Active Area | 64.51*14.5 |
