128x32 Graphic Transflective ST7565R Monochrome STN LCD Display Module
Resolution & Pixel Pitch: Various pixel pitches available (e.g., P1.25, P2.5, P4) to ensure high-definition displays for different a
Size & Shape: Customizable screen sizes and shapes, including standard rectangular, curved, and irregul
Brightness & Protection Level: Adjustable brightness (1000 to 5000 nits) and protection levels (e.g., IP65 waterproof) tailored for indoor or outdoor u
Control System & Features: Customizable control systems with options for multiple playback modes, interactive touch functionality, a
Introduction
| Type | Monochrome STN LCD module | Display Size | 2 inch STN module |
| Supplier Type | Manufacturer | Display Typ | STN |
| Controller | ST7565R | Format | 128X 32 Dots |
| Viewing Area | 36.0*12.0MM | LCM Outline Dimension | 39.6*22.5*2.0 mm |
| Polarize Type | Transflective | Viewing Direction | 6 O'clock |
| Driving Mode | 1/33Duty, 1/6Bias | Input Data | 4-Line SPI |
| Compliance | REACH and RoHS Complicant |
